Tech specs
- Telephone Interfaces: 2 x RJ11 FXS ports
- Network Interface: 1 x 10/100Mbps auto-sensing ethernet port (RJ45)
- Telephony Features: Caller ID display or block, call waiting, flash, blind or attended transfer, forward, hold, do not disturb, 3-way conference
- Voice Codecs: G.711 with Annex I (PLC) and Annex II (VAD/CNG), G.722, G.723.1, G.729A/B, G.726-32, iLBC, OPUS, dynamic jitter buffer, advanced line echo cancellation
- Fax Over IP: T.38 compliant Group 3 Fax Relay up to 14.4kpbs and auto-switch to G.711 for Fax Pass-throug
- Short/Long Haul Ring Load: 2 REN (Up to 1km on 24 AWG)
- Caller ID: Bellcore Type 1 & 2, ETSI, BT, NTT, and DTMF-based CID
- Dial Methods: DTMF, Pulse
- Disconnect Methods: Busy Tone, Polarity Reversal/Wink, Loop Current
- Network Protocols: TCP/IP/UDP, RTP/RTCP (RFC1889, 1890), HTTP/HTTPS, ARP/RARP, ICMP, DNS, DHCP, NTP, TFTP, SSH, Telnet, STUN (RFC3489, 5389), SIP (RFC3261), SIP over TCP/TLS, SRTP, SNMP, TR-069, IMS/3GPP, IPoE
- Management: Syslog support, SSH, remote management using web browser
- Operating Environment: Temperature 0°C to 40°C (32°F to 104°F); Humidity: 10% to 90% Non-condensing
Box Contents
- 1 x HT802 V2
- 1 x Power Supply
